Description
Part Number: AF100-20-1M
AeroFlow 100 Series -20 AN Stainless Steel Braided Hose (1 Metre)
Constructed with a seamless CPE synthetic rubber inner liner and reinforced with high-tensile 308 stainless steel outer braiding, the AeroFlow AF100-20-1M delivers maximum fluid compatibility, flexibility, and pressure resistance for high-performance motorsport applications.
Key Features & Benefits
- ✓ Premium CPE synthetic rubber inner liner resistant to synthetic lubricants, oils, coolants, and fuels
- ✓ High-tensile 308 stainless steel outer braid provides superior abrasion and impact protection
- ✓ Rated for extreme temperature ranges from -40°C to +150°C (-40°F to +302°F)
- ✓ Designed for use with AeroFlow 100 Series re-usable hose ends and fittings
- ✓ Ideal for heavy-duty motorsport oil lines, dry sump systems, and high-flow radiator plumbing
| Brand | AeroFlow |
|---|---|
| Part Number | AF100-20-1M |
| Hose Size | -20 AN (1-1/8″) |
| Length | 1 Metre (3.28 ft) |
| Inner Diameter | 28.57mm (1.125″) |
| Outer Diameter | 37.30mm (1.468″) |
| Inner Liner | CPE Synthetic Rubber |
| Outer Braid | 308 Stainless Steel |
What’s Included in the Box
- 1 x 1 Metre Length of AeroFlow AF100-20-1M -20 AN 100 Series Stainless Steel Braided Hose
Engineered to strict quality standards by AeroFlow Performance, this hose guarantees maximum durability under severe race conditions. Order today from JP Racing for immediate UK stock availability, expert technical support, and rapid nationwide delivery.
