Description
Part Number: 80118
FiTech Ultimate LS 750HP EFI System with Transmission Control
Complete self-learning fuel injection and electronic transmission management for GM LS engine swaps.
Key Features
- ✓ Designed for naturally aspirated GM LS engines up to 750 HP
- ✓ Integrated electronic transmission control for 4L60E, 4L65E, 4L80E, and 4L85E
- ✓ Self-learning ECU with full-colour handheld touch-screen programmer
- ✓ High-flow fabricated black sheet metal intake manifold with 102mm throttle body
- ✓ Includes 55 lb/hr fuel injectors, high-flow fuel rails, and complete plug-and-play wiring
Technical Specifications
| Manufacturer | FiTech Fuel Injection |
|---|---|
| Part Number | 80118 |
| Intake Port Style | Cathedral Port (LS1/LS2/LS6) |
| Max Horsepower Rating | 750 HP |
| Throttle Body Diameter | 102mm Billet Aluminum |
| Injector Size | 55 lb/hr |
| Transmission Control | 4L60E / 4L65E / 4L80E / 4L85E |
What’s Included in the Box
- Fabricated Sheet Metal Intake Manifold (Black Anodized)
- 102mm Cable-Operated Throttle Body
- 55 lb/hr High-Impedance Fuel Injectors & Billet Fuel Rails
- FiTech Ultimate LS ECU & Handheld Touch-Screen Controller
- Transmission Control Harness & Main Engine Wiring Harness
- Wideband Bosch O2 Sensor, MAP Sensor, Coolant Temp Sensor, and Mounting Hardware
Engineered for uncompromising street and track performance, FiTech’s Ultimate LS 750HP system removes the guesswork from modern engine swaps. Order through JP Racing for expert UK technical support, guaranteed genuine FiTech components, and fast dispatch across the UK and Europe.
