AutoMeter Universal Magnetic Hall Effect Speed Sensor Kit
High-precision speed signal solution for electric programmable speedometers on custom and motorsport applications.
Product Overview
The AutoMeter 5290 Universal Magnetic Hall Effect Speed Sensor is engineered to supply a clean, reliable 12V square wave signal directly to AutoMeter electric programmable speedometers and aftermarket digital displays. Ideal for custom vehicle builds and race machinery where traditional transmission or gearbox sensor take-offs are unavailable, this kit mounts directly to axles, driveshafts, or tailshafts to measure driven wheel speed accurately.
Key Features
- ☑ Hall Effect Sensor Technology: Delivers a consistent 12V square wave output unaffected by temperature or signal drift.
- ☑ 4 Pulse Per Revolution Output: Standard 4 PPR signal output for accurate speedometer pulse calibration.
- ☑ Universal Driveshaft / Axle Mounting: Ideal solution when transmission speedo cable drives are absent or inaccessible.
- ☑ 3-Wire Connection: Straightforward wiring harness setup requiring 12V power, signal output, and ground.
- ☑ Complete Installation Kit: Supplied with 3/8″-24 threaded pickup probe, 4 trigger magnets, mounting bracket strap, and hardware.
Technical Specifications
| Manufacturer | AutoMeter |
|---|---|
| Part Number | 5290 |
| Sensor Type | Hall Effect Magnetic Speed Sensor |
| Signal Output | 12V Square Wave |
| Pulses Per Revolution (PPR) | 4 PPR |
| Sensor Probe Thread | 3/8″-24 UNF |
| Wiring Configuration | 3-Wire (Red 12V Power, White Signal, Black Ground) |
| Fitment Type | Universal (Axle / Driveshaft / Tailshaft) |
What’s Included in the Box
- 1x AutoMeter 5290 Threaded Hall Effect Speed Sensor Pickup with Wire Lead
- 4x High-Strength Drive Magnets
- 1x Universal Steel Mounting Bracket Assembly
- 1x Mounting Hardware & Wiring Kit
Built to AutoMeter’s rigorous motorsport standards, the 5290 universal speed sensor provides reliable speed data under demanding track and road conditions. Order directly from JP Racing for expert technical support and fast UK delivery.
