Description
Part Number: AF101-06S
AeroFlow 100 Series Stainless Steel Braided Hose -06AN
Premium high-performance flexible hose engineered for high-pressure fuel, oil, coolant, and methanol systems in competitive motorsport applications.
Key Features
- ✓ High-grade 308 stainless steel outer braid for superior abrasion resistance and durability
- ✓ CPE synthetic rubber inner core suitable for synthetic lubricants, coolants, and most fuels
- ✓ Designed to withstand extreme vibration, high operating pressures, and severe temperature fluctuations
- ✓ Fully compatible with AeroFlow 100 and 500 series re-usable hose ends
- ✓ Ideal for custom fuel delivery, dry-sump oiling systems, and transmission cooling lines
Technical Specifications
| Specification | Detail |
|---|---|
| Brand | AeroFlow Performance |
| MPN | AF101-06S |
| Hose Size | -06 AN |
| Internal Diameter (ID) | 8.73mm (11/32″) |
| Outer Diameter (OD) | 13.89mm (35/64″) |
| Inner Liner Material | CPE Synthetic Rubber |
| Outer Braid | 308 Grade Stainless Steel |
| Operating Pressure | 1,000 PSI |
| Burst Pressure | 5,000 PSI |
| Temperature Range | -40°C to +150°C (-40°F to +302°F) |
What’s Included in the Box
- 1x AeroFlow AF101-06S 100 Series Stainless Steel Braided Hose (Sold per metre)
AeroFlow Performance products are renowned globally for precision manufacturing and reliability under harsh racing conditions. JP Racing is an authorized UK distributor offering dedicated technical support and swift UK nationwide dispatch on all stock.
