ClearView 100-60-B See-Through 6″ Oil Filter – Black Anodised Edition

Description

ClearView 100-60-B See-Through 6″ Oil Filter – Black Anodised Edition

Combine ultimate engine protection with a sleek, stealth aesthetic. The ClearView 100-60-B in Black Anodised is the professional’s choice for high-performance oil filtration.

Engineered for the most demanding racing and automotive environments, the ClearView 100-60-B is a revolutionary diagnostic tool disguised as a high-flow oil filter. This “Black Edition” features a deep, hard-anodised finish on its billet aluminium housing, designed to integrate seamlessly into modern, “blacked-out” engine bays while providing industry-leading protection.

Patented Visual Diagnostics

The core of the 100-60-B is its patented “See-Through” design. This allows you to monitor your oil’s health in real-time, catching issues like aeration, fuel dilution, or coolant leaks before they lead to catastrophic engine failure. By using the integrated air fitting, you can clear the oil from the assembly in seconds, allowing for a thorough inspection of the 60-micron filter element without draining your sump.

Engineered for High-Volume Flow

Built for high-horsepower applications—from Pro Mod drag racers to high-performance marine engines—this filter features a massive 6-inch body and four -12 AN O-ring ports. The 60-micron stainless steel mesh is specifically optimised for 50-weight oil or lighter, ensuring that even high-volume oiling systems never face a bottleneck.

Stealth Black Finish & Durability

The Black Anodised coating is more than just a colour choice; it is a durable, chemically bonded layer that provides exceptional resistance to heat, chemicals, and abrasion. The matte-black aesthetic offers a professional, understated look that won’t distract from other engine components, while still providing the ruggedness required for track-side maintenance.

Key Features:

• See-Through Inspection Window: Instant visual confirmation of oil flow and condition.

• On-Engine Servicing: Empty the filter with a standard air chuck to inspect for metal debris or contaminants without an oil change.

• High-Flow 60-Micron Element: Reusable stainless steel mesh for maximum flow and filtration.

• Versatile Plumbing: Equipped with two inlet and two outlet -12 AN ports for flexible installation.

• Safety Bypass Valve: Features a built-in relief valve to ensure your engine is never starved of oil.

• Hard-Anodised Black Finish: Provides a stealthy, high-end look with maximum corrosion resistance.

Why Choose the Black Anodised Version?

The Black Anodised 100-60-B is perfect for builders who want a modern, integrated look. It hides fingerprints and grease better than polished finishes and is the ideal match for contemporary AN fittings and braided lines. If you demand “stealth” styling without compromising on the ability to diagnose engine health, this is your filter.

Technical Specifications:

• SKU: 100-60-B

• Filter Style: Inline High-Flow See-Through

• Material: Billet Aluminium / Stainless Steel Mesh

• Finish: Black Anodised

• Micron Rating: 60 Microns

• Port Size: -12 AN O-Ring Boss (1 1/16” – 12 TPI)

• Max Operating Pressure: 150 PSI

• Max Operating Temp: 104°C (220°F)

• Dimensions: 7.75″ Length x 6.75″ Width x 3.25″ Height

• Included: Black Filter Assembly, 60 Micron Element, and Mounting Bracket Kit

With over 27 years of experience, Meziere Enterprises remains a family-owned leader in cooling technology. Their commitment to value begins with innovative designs that solve real-world performance problems, backed by exceptional American manufacturing and rigorous quality control. When you choose Meziere, you are investing in a product designed to outlast and outperform the competition.
