Brian Crower Stage 3 N/A Single Intake Camshaft – Honda B16A / B18C
Engineered for high-RPM, fully built naturally aspirated Honda B-Series engines seeking maximum top-end performance.
Product Overview
The Brian Crower BC0013I Stage 3 Intake Camshaft is precision-engineered for race-spec naturally aspirated Honda B16A, B17A, and B18C DOHC VTEC engines. Featuring an aggressive lobe profile with 310° advertised duration and .496″ (12.60 mm) valve lift, this single intake camshaft maximizes high-RPM cylinder filling and volumetric efficiency. Designed for drag, track, and high-compression NA builds, it requires upgraded valvetrain components (BC0010 or BC0010S spring/retainer kits) and custom ECU tuning to unleash peak power above 8,000 RPM.
Key Features
- ☑ Stage 3 N/A Race Profile: Specifically engineered for high-compression, fully built naturally aspirated B-series engines.
- ☑ High Lift & Duration: Delivers 310° advertised duration (260° @ .050″) and .496″ (12.60 mm) valve lift for peak power output.
- ☑ Precision Machining: Manufactured from chilled cast cores, CNC ground and micro-polished for extreme timing consistency and durability.
- ☑ Honda VTEC Fitment: Direct compatibility with Honda and Acura B16A, B17A, and B18C DOHC VTEC cylinder heads.
- ☑ Single Intake Component: Supplied as individual 1pc intake camshaft (MPN: BC0013I) for custom valvetrain setups or direct replacement.
Technical Specifications
| Manufacturer | Brian Crower (BC) |
|---|---|
| Part Number | BC0013I |
| Component Type | Single Intake Camshaft (1pc) |
| Stage Specification | Stage 3 Normally Aspirated (N/A) Race Spec |
| Engine Fitment | Honda / Acura B16A, B17A, B18C (DOHC VTEC) |
| Advertised Duration | 310° |
| Duration @ .050″ | 260° |
| Valve Lift (1.55:1 Ratio) | .496″ / 12.60 mm |
| Required Valvetrain | BC0010 or BC0010S Valve Spring & Retainer Kit |
| Cam Gear Torque Spec | 22 ft-lbs (30 Nm) — Do NOT use impact tools |
What’s Included in the Box
- 1x Brian Crower Stage 3 N/A Intake Camshaft (BC0013I)
- 1x Official Camshaft Specification Card
At JP Racing, we supply authentic Brian Crower high-performance valvetrain parts with fast UK dispatch and expert technical advice. Elevate your Honda competition motor with proven motorsport components.
