Description
Part Number: BC6016-1
Brian Crower Single I-Beam Extreme Connecting Rod with ARP625+ Fasteners (Honda / Acura B18A/B18B, B20)
Engineered for extreme boost and high-RPM motorsport applications, the Brian Crower BC6016-1 single I-Beam Extreme connecting rod offers ultimate structural integrity for Honda and Acura 1.8L non-VTEC and 2.0L engine builds.
Key Features & Engineering
- ☑ Precision forged from 4340 aerospace-grade chromoly steel for maximum tensile strength and fatigue resistance.
- ☑ Heavy-duty I-Beam Extreme design engineered to withstand severe cylinder pressures, high boost levels, and high RPM loads.
- ☑ Equipped with ultra-high-strength ARP Custom Age 625+ rod bolts rated to over 260,000 psi yield strength.
- ☑ Micropolished surface finish treatment eliminates stress risers for optimal fatigue life under race conditions.
- ☑ Precision aluminum/silicone/bronze wrist pin bushings for low friction and maximum wear durability.
- ☑ Ideal single replacement rod (1pc) for engine rebuilds or individual replacement in existing BC6016 sets.
Technical Specifications
| Brand | Brian Crower (BC) |
|---|---|
| Manufacturer Part Number | BC6016-1 |
| Engine Compatibility | Honda / Acura B18A, B18B, B20 (Non-VTEC 1.8L & 2.0L) |
| Beam Style | I-Beam Extreme (“MOAR” Series) |
| Material | 4340 Forged Chromoly Steel |
| Center-to-Center Length | 5.394″ (137.01 mm) |
| Big End Bore (BE Bore) | 1.890″ (48.00 mm) |
| Big End Width (BE Width) | 0.892″ (22.65 mm) |
| Pin End Bore (PE Bore) | 0.827″ (21.00 mm) |
| Included Fasteners | ARP Custom Age 625+ Rod Bolts (3/8″ thread) |
| Torque Specification | 50 ft-lbs (with ARP Ultra-Torque lubricant) |
| Quantity Supplied | 1 Connecting Rod (Single Piece) |
What’s Included in the Box
- 1 x Brian Crower BC6016-1 I-Beam Extreme Connecting Rod
- 2 x ARP Custom Age 625+ 3/8″ Rod Fasteners
- 1 x Assembly Lubricant & Specification Card
At JP Racing, we supply genuine Brian Crower race components to professional engine builders and motorsport competitors across the UK. Every Brian Crower connecting rod undergoes rigorous quality inspection and precision machining to deliver reliable performance under demanding track conditions. Contact our expert UK technical sales team today for fitment guidance and rapid UK delivery.
