AEROFLOW 13.5 x 9″ COMP TRANS COOLER WITH 120w FAN & SWITCH -10ORB

Description

AEROFLOW 13.5 x 9″ COMP TRANS COOLER WITH 120w FAN & SWITCH -10ORB

AEROFLOW 13.5 x 9″ COMP TRANS COOLER WITH 120w FAN & SWITCH -10ORB Competition Oil & Transmission Cooler -10 ORB, 13-1/2″ x 9″ x 3-1/2″, with Fan & SwitchAeroflow’s engine and transmission competition oil coolers feature -10ORB female fittings, thermostat, wiring plug kit and a high quality electric fan. It accepts engine oil, transmission and power steering applications and has been pressure tested to over 200psi.The M18 x 1.50mm thermal switch included in the top of the oil cooler activates the fan at 175°F/79.5°C. The cooler also features a fin and plate construction. The dimensions are 13-1/2″(342mm) x 9″(228mm).The 9-1/2″ (241mm) electric fan can be reversed for mounting either side of the heat exchanger. They are boxed in the pusher configuration. To change this to a puller fan simply unscrew 10mm nut (reverse (left hand) thread) and turn fan blade over keeping in mind polarity BLUE – Positive BLACK – Negative. Overview Description: AEROFLOW 13.5 x 9″ COMP TRANS COOLER WITH 120w FAN & SWITCH -10ORB Part Number: AF72-6001 Supplier: Aeroflow Features/Specs Since 2010, Aeroflow Performance Products has grown to design and manufacture close to 11,000 exceptional quality products. Fittings and hoses, fuel system components, air and oil filters, oil systems, silicone hoses, fabricated tanks, alternators, workshop tools and much more. As a company, they have tried to lead the way for the Performance enthusiast. –> Aeroflow Website
