Part Number: AF72-4010
Aeroflow 10 Row Modular Oil Cooler (330mm x 77mm x 51mm)
Engineered for ultimate thermal management, the Aeroflow AF72-4010 10-row modular oil cooler delivers exceptional fluid temperature control for performance engines, transmission systems, and auxiliary oil circuits.
Key Features
- ☑ Fully brazed modular stacked-plate aluminum construction for supreme structural durability.
- ☑ Heavy-duty brazed seams designed to resist severe vibrations and pressure pulsations in motorsport environments.
- ☑ High-efficiency 10-row core delivering heat dissipation up to 20,000 BTU/hr.
- ☑ Dual -10 Female ORB (O-Ring Boss) ports for leak-free, reliable adapter connections.
- ☑ Universal design suitable for engine oil, automatic transmission fluid, differential oil, or power steering.
Technical Specifications
| Brand | Aeroflow Performance |
|---|---|
| Manufacturer Part Number | AF72-4010 |
| Cooler Style | Modular Stacked Plate Oil Cooler |
| Number of Rows | 10 Row |
| Overall Dimensions | 330mm Length x 77mm Height x 51mm Depth |
| Port Thread Specification | -10 Female ORB Threads (-10AN O-Ring Boss) |
| Heat Dissipation Rating | 20,000 BTU / hour |
| Maximum Working Pressure | 10 Bar (145 PSI / 1 MPa) |
| Burst Pressure Rating | 25 Bar (362 PSI / 2.5 MPa) |
What’s Included in the Box
- 1 x Aeroflow AF72-4010 10-Row Modular Oil Cooler (-10 ORB Ports)
- Protective Transit Port Plugs
Aeroflow Performance components are manufactured using state-of-the-art processes and premium materials to ensure maximum reliability on track and street. As a dedicated UK motorsport supplier, JP Racing offers expert technical guidance and fast UK delivery across the full Aeroflow fluid cooling lineup.
