MSD Blaster SS Ignition Coil, Black

Description

MSD Blaster SS Ignition Coil, Black

Note: If installing the Blaster SS Coil to a points distributor or a non-current limiting ignition system without an MSD Ignition, a 0.8 ohm ballast resistor is required (MSD PN 8214). The resistor should wire in series along with any factory resistors on the positive coil wire.

Overview

• Description: Blaster SS Ignition Coil
• Colour: Black
• SKU: 82073
• Supplier: MSD
• Instructions: Click to Download

Don’t let the compact size of the Blaster SS Coil fool you, because it is packed with performance! The efficient E-core windings are designed to produce high amounts of current without sacrificing the voltage output. In fact, when used with an MSD 6 Series Ignition, the Blaster SS produces 300 milliamps with a maximum voltage output of 40,000 volts!

Features

• Improved output coil for electronic ignitions, and MSD Ignitions
• Efficient winding design and assembly creates a compact housing
• Tough, rigid housing with a tall tower and brass primary terminals
• CARB E.O. D-40-37
• Primary and secondary windings are encased in Ciba polyurethane
• 70:1 turns ratio and lower primary resistance produce high voltage output

Technical

• C.A.R.B. EO #: D-40-37
• Coil Type: Blaster
• Inductance (mH): 6.9
• Maximum Voltage: 40,000
• Part Type: Ignition Coil
• Peak Current@ 300 4K
• Primary Resistance: 0.355 82
• Secondary Resistance: 4.4K 82
• Spark duration: 0.22 MESC
• Turns Ratio: 2.92
• Warranty: Manufacturer’s Limited 1 Year Warranty
• Weight 1.08 LB
• UPC 085132820733

From small block street cruisers to 10,000 horsepower top fuel dragsters, MSD’s ignition systems has been the industry leader for over 40 years. MSD continues to push the envelope with cutting-edge ignition technology as well as intake manifolds and EFI systems.
