Description
Part Number: AF49-4048
Aeroflow 3 Wire Electrical Terminal Bulkhead – Black Negative Wires
Engineered for high-amp fuel cell projects and retrofitting billet triple fuel pump hangers with leak-free hermetic sealing.
Key Features
- ☑ Triple Staging Capability: Features three individual 14AWG black negative ground wires to independently wire and stage up to three in-tank fuel pumps.
- ☑ High Ampere Rating: Each 14AWG Tefzel wire is rated up to 30 amps to power high-demand aftermarket fuel pumps safely.
- ☑ Hermetic Leak-Free Seal: Precision billet bulkhead incorporates a hermetic wire seal and Viton underside O-ring to prevent fuel and vapor leaks.
- ☑ Direct Retrofit Fitment: Designed as a direct upgrade for Aeroflow Performance billet triple pump hangers in place of single electrical terminal bulkheads.
- ☑ Complete Terminal Kit: Fuel-side wires pre-terminated with Delphi terminals and supplied with a 2-pin male plug for clean in-tank assembly.
Technical Specifications
| Brand | AeroFlow Performance |
|---|---|
| Manufacturer Part Number | AF49-4048 |
| Wire Lead Configuration | 3 x 14AWG Tefzel Wires (Black / Negative Ground) |
| Current Rating | Up to 30 Amps per wire |
| Seal Construction | Hermetic Seal with Viton O-Ring |
| Application Compatibility | Aeroflow Billet Triple Fuel Pump Hangers & Custom Fuel Cells |
What’s Included in the Box
- 1 x Aeroflow Billet 3-Wire Terminal Bulkhead (Black Tefzel Lead Assembly)
- 1 x Viton Underside O-Ring Seal
- Delphi Internal Electrical Terminals
- 1 x 2-Pin Male Electrical Plug Kit
Manufactured to strict motorsport standards by AeroFlow Performance, this electrical terminal bulkhead delivers reliable current transfer for high-performance fuel delivery systems. Order from JP Racing today to benefit from expert technical assistance and fast dispatch directly across the UK.
