Description
Part Number: AF25-2000
Aeroflow 2″ Billet Aluminium Quick Connect Intercooler Clamp – Polished
Engineered for extreme boosted performance, the Aeroflow AF25-2000 2″ polished billet aluminium quick-connect clamp system provides a modular, leak-free connection designed to eliminate boost leaks and hose blow-offs under extreme pressure.
Key Features & Benefits
- ☑ 6061-T6 Billet Construction: Precision CNC-machined from high-tensile 6061-T6 aircraft-grade aluminium for maximum strength and structural rigidity.
- ☑ 500+ PSI Burst Rating: Engineered and tested to withstand internal boost pressures exceeding 500 PSI without flexing or leaking.
- ☑ Dual O-Ring Union Sleeve: Features a grooved inner sleeve with dual high-temp O-rings for complete airtight seal integrity and thermal movement tolerance.
- ☑ Quick-Release Outer Ring: Hard-anodised quick-release clamp allows fast tear-down during trackside tuning and intercooler maintenance.
- ☑ Show-Quality Polished Finish: Mirror-polished outer finish delivers an exceptional aesthetic under the bonnet.
Technical Specifications
| Brand | Aeroflow Performance |
|---|---|
| Manufacturer Part Number | AF25-2000 |
| Tube Outer Diameter | 2.0″ (51mm) |
| Material | 6061-T6 Billet Aluminium |
| Finish | Polished |
| Burst Pressure Rating | >500 PSI |
| Clamp Width | 26mm |
| Overall Assembly Length | 92mm |
| Sealing System | Internal Sleeve with Dual Nitrile O-Rings |
What’s Included in the Box
- • 1 x Aeroflow 2″ Polished Billet Aluminium Quick-Release Outer Clamp
- • 2 x 2″ Weld-On Aluminium Pipe Ferrules
- • 1 x Anodised Internal Union Sealing Sleeve
- • 2 x High-Temperature Nitrile O-Rings
- • 1 x Locking Pin and Assembly Hardware
Aeroflow Performance components are engineered to strict motorsport tolerances, delivering ultimate dependability for competitive motorsport and high-horsepower street builds. Order your AF25-2000 quick-connect clamp kit from JP Racing today for direct UK technical assistance and rapid dispatch.
