Description

Part Number: 1302

AutoMeter Arctic White 5-Piece Electric Gauge Kit

Classic street rod aesthetics engineered with race-proven air-core precision instrumentation.

Key Features

☑ Complete 5-gauge ensemble featuring 3-1/8″ electric speedometer and four 2-1/16″ auxiliary gauges.
☑ High-contrast Arctic White dial faces with bold black numerals, vibrant red pointers, and polished chrome bezels.
☑ Simple push-button 2-mile drive calibration for the electronic speedometer with lit LCD odometer and tripmeters.
☑ Race-tested air-core electric movement for instantaneous readings while keeping hazardous fluids out of the cabin.
☑ Perimeter incandescent lighting with red and green bulb covers included for custom night-time dash illumination.

Technical Specifications

Brand	AutoMeter
Part Number	1302
Series	Arctic White
Gauge Type	5-Piece Electric Gauge Kit
Speedometer Size & Type	3-1/8″ (79.4mm) Electric (0-120 MPH)
Auxiliary Gauge Size	2-1/16″ (52.4mm) Electric
Included Auxiliary Gauges	Water Temp (100-250 °F), Oil Press (0-100 PSI), Voltmeter (8-18V), Fuel Level (240Ω E / 33Ω F)
Bezel Finish	Chrome
Lighting Style	Perimeter Incandescent Lighting
Electrical Voltage	12V & 16V Compatible

What’s Included in the Box

3-1/8″ Electric Speedometer (0-120 MPH)
2-1/16″ Electric Water Temperature Gauge
2-1/16″ Electric Oil Pressure Gauge
2-1/16″ Electric Voltmeter
2-1/16″ Electric Fuel Level Gauge (240E / 33F)
Speed Sensor / VSS (PN 5293 – 2-Wire Hall-Effect, 7/8″-18 Thread)
Oil Pressure Sender (PN 2242 – 1/8″ NPT)
Water Temperature Sender (PN 2258 – 1/8″ NPT)
Fuel Level Sender (PN 3262)
NPT Adapter Fittings (1/4″, 3/8″, 1/2″ NPT)
Bulb & Socket Assemblies with Red & Green Covers
Gauge Mounting Brackets & Hardware Pack

AutoMeter instruments represent the gold standard in vehicle instrumentation and durability. As a leading UK high-performance motorsport supplier, JP Racing delivers genuine AutoMeter products backed by specialist technical assistance, competitive pricing, and fast UK dispatch to keep your vehicle project moving forward.

Additional information

Weight	2.2 kg
Dimensions	11.43 × 45.09 × 22.23 cm

Frequently Asked Questions

The 3-1/8" electronic speedometer features a push-button 2-mile calibration system. Drive a measured 2-mile distance and press the calibration button; the internal microprocessor automatically stores the speed sensor pulse frequency. No dip switches or calculation formulas are required, and the unit can be recalibrated at any time if wheel sizes or axle ratios change.

AutoMeter 1302 includes a complete sender suite: a 2-wire Hall-effect speed sensor (7/8"-18 thread for GM/Chrysler applications), 1/8" NPT oil pressure sender, 1/8" NPT water temperature sender, and a fuel level sender (240E/33F). Thread adapter bushes for 1/4", 3/8", and 1/2" NPT ports are also included.

The included fuel level gauge operates specifically on a 240 Ohms Empty to 33 Ohms Full resistance sweep. While the kit includes a matching AutoMeter fuel sender (PN 3262), it can also be wired to existing fuel tank senders provided they share the exact 240-33 Ohm range.
