Description
Part Number: AF200-20-1MBLK
Aeroflow 200 Series -20AN PTFE Stainless Steel Braided Hose (1m, Black)
Engineered for high-performance motorsport and severe service applications, the Aeroflow 200 Series PTFE hose combines a smooth PTFE inner liner with a protective 308 stainless steel outer braid in a clean black finish.
Key Features
- ☑ Chemically inert PTFE inner liner resists fuel vapor permeability and chemical degradation.
- ☑ Black coated 308 stainless steel outer braid offers superior abrasion resistance and sleek aesthetics.
- ☑ Compatible with E85, ethanol, methanol, race fuel, oil, power steering, hydraulics, and vacuum lines.
- ☑ Rated for high pressure service with 1000 PSI operating pressure and 2500 PSI burst pressure.
- ☑ Broad operational temperature range from -70°C to 250°C (-94°F to 482°F).
Technical Specifications
| Brand | Aeroflow Performance |
|---|---|
| Part Number | AF200-20-1MBLK |
| Hose Series | 200 Series PTFE |
| AN Size | -20AN |
| Length | 1 Metre |
| Inside Diameter (ID) | 28.45mm (1-1/8″) |
| Outside Diameter (OD) | 32.77mm (1-9/32″) |
| Operating Pressure | 1000 PSI (68.94 Bar) |
| Burst Pressure | 2500 PSI (172.37 Bar) |
| Temperature Range | -70°C to 250°C (-94°F to 482°F) |
| Max Bend Radius | 575mm (22-41/64″) |
What’s Included in the Box
- 1x Aeroflow 200 Series -20AN PTFE Stainless Steel Braided Hose – 1 Metre (Black)
Aeroflow Performance fluid transfer components deliver proven reliability for track and road builds. Order the AF200-20-1MBLK from JP Racing today to benefit from fast UK shipping and dedicated technical customer support.
