WOSP High Torque Starter Motor, Ford V4 V6 Essex Capri Consul Granada, TVR Taimar 3000M 3000S

Description

WOSP High Torque Starter Motor, Ford V4 V6 Essex Capri Consul Granada, TVR Taimar 3000M 3000S

Designed and manufactured in house using only OE platforms, these lightweight, gear reduction and high torque starter motors are ideal for use in hostile or bespoke environments and are warranted for 12 months and in most cases offer twice the power and half the current draw and weight to an original unit. Unless specifically intended for just one application all our units can be rotated 360° on their own axis giving the unit an infinite number of mounting positions to clear any obstruction.

Overview

• Description: WOSP High Torque Starter Motor, Ford V4 V6 Essex Capri Consul Granada, TVR Taimar 3000M 3000S
• Supplier: WOSP
• Part Number: LMS014
• Type: Denso OSGR *r
• Weight: 3.7 KG / 8.15 LBS
• Voltage: 12V
• Polarity: Both
• Power: 1.4kW
• Rotation: CW
• Pinion Teeth: 9
• Pinion ⌀: 29mm

Fitments

• Ford Capri 2.L / 3L Petrol EV20L / EV20HL / TV20L / TV30HYP / TV30HYT Mk I / II / III ( ECJ / GECP ) ’69-’81
• Ford Consul 3.0 Petrol EV30 MK II ( GCU / GNU / GGC ) ’72-’75
• Ford Granada 3.0 Petrol EV30 Mk I ( GF / GT / GC / GN ) ’72-’77
• Ford Essex V4
• Ford Essex V6
• Marcos – Ford Essex V6
• Reliant Scimitar 3.0 Petrol TV30 (3L Essex) SE5 / SE6 ( TW ) ’68-’75
• TVR Taimar (3L Essex)
• TVR 3000M (3L Essex)
• TVR 3000S (3L Essex)
• Suits 121 tooth flywheel

Documents

• Installation Instructions

WOSPerformance have been manufacturing and supplying bespoke starting and charging systems via a dealer network for decades. They are a family-run company which refuses to be beaten on service and quality, whilst pushing the boundaries of what is possible.

Widely regarded as the world leader with over 1500 starter applications and alternators to suit almost any possible requirement, all units are built to the highest standards using only original specification parts.
