Description
Part Number: AF37-0602BLK
Aeroflow 2.5″ Anodized Black Blower Stud Kit
Engineered from high-tensile 6061-T6 aluminium to act as a breakaway safety mechanism for supercharger assemblies, protecting engine blocks and manifolds during backfires.
Key Features
- ☑ 6061-T6 Aluminium Construction: Machined from aerospace-grade aluminium for lightweight strength and controlled sheer tolerance.
- ☑ Sacrificial Breakaway Function: Snaps intentionally during severe backfires to vent overpressure, preventing catastrophic manifold and supercharger casing destruction.
- ☑ Dual Thread Specification: Features 7/16″ UNC thread into the manifold/blower and 7/16″ UNF thread on the nut side.
- ☑ Black Anodized Finish: Delivers superior chemical and corrosion resistance with a clean, stealth appearance.
- ☑ Complete Hardware Kit: Supplied with 12-point high-tensile steel nuts and hardened steel washers for a secure installation.
Technical Specifications
| Brand | Aeroflow Performance |
|---|---|
| Part Number | AF37-0602BLK |
| Material | 6061-T6 Aerospace Aluminium |
| Finish | Black Anodized |
| Overall Length | 63mm (2.50″) |
| Blower / Manifold Thread | 7/16″ UNC |
| Nut Side Thread | 7/16″ UNF |
| Torque Specification | 15 ft-lbs (20 Nm) |
What’s Included in the Box
- • 8 x Aeroflow 2.5″ Black Anodized Aluminium Blower Studs (7/16″ UNC / UNF)
- • 8 x 12-Point High-Strength Steel Nuts
- • 8 x Hardened Steel Washers
As an official UK supplier of Aeroflow Performance hardware, JP Racing offers rapid UK shipping and dedicated technical support. Build your forced induction system with confidence using track-proven protection.
