Description
Part Number: 3967
AutoMeter Sport-Comp 5″ Pedestal Mount Playback Tachometer (0-11,000 RPM)
Master your shift points and analyze full drag or circuit runs with the AutoMeter 3967 Sport-Comp 5″ Playback Tachometer, engineered for ultimate precision and data analysis.
Key Features & Performance Highlights
- ☑ 80-Second Data Playback: Record up to 80 seconds of engine RPM data and play back at 1:1 or 1:3 slow-motion speeds to analyze burnout, launch RPM, tire spin, and gear changes.
- ☑ Lightning-Fast Air-Core Movement: AutoMeter’s race-proven air-core movement sweeps the needle from 0 to 11,000 RPM in just 333 milliseconds with extreme precision.
- ☑ Short-Shift Protection: Intelligent RPM drop monitoring prevents missed shifts caused by premature gear changes.
- ☑ Classic Sport-Comp Styling: Black dial face, high-contrast white numerals, fluorescent red pointer, and perimeter incandescent lighting for quick visual reference.
- ☑ Universal Ignition Compatibility: Works with 0.5 to 6 pulse ignition signals (1 to 12-cylinder engines) across 12V and 16V race electrical systems.
Technical Specifications
| Brand | AutoMeter |
|---|---|
| Part Number | 3967 |
| Series | Sport-Comp |
| Gauge Diameter | 5″ / 127mm |
| Gauge Type | Electric Air-Core Tachometer with Playback |
| RPM Range | 0 – 11,000 RPM |
| Mounting Style | Pedestal Mount (Bracket Included) |
| Dial / Bezel Finish | Black Dial Face / Silver Brushed Aluminum Bezel |
| Lighting Type | Perimeter Incandescent Lighting (White) |
| Operating Voltage | 12V & 16V Compatible |
| Engine Compatibility | 1 – 12 Cylinder Engines (0.5 – 6 Pulse Ignition Signals) |
What’s Included in the Box
- • AutoMeter 3967 Sport-Comp 5″ Pedestal Playback Tachometer
- • Heavy-duty Pedestal Mounting Bracket & Hardware
- • Bulb and Socket Assembly (3219) with Red/Green Lens Covers
- • Wiring Harness & Remote Recording Trigger Lead
- • Mounting Hardware & Installation Fasteners
Built to endure the rigorous conditions of track and drag strip motorsport, AutoMeter instruments set the standard in high-performance racing. Order your AutoMeter 3967 tachometer from JP Racing today for authentic motorsport hardware backed by expert UK technical support and fast UK delivery.
